Excavator Spare Parts 1U3351 Heavy Duty Bucket Short Tooth Point J350 Casting Bucket Teeth

1U3351 J350  General Purpose Tip — Product Description

For fleet managers running J350 class class rippers, the 1U3351 tip is the cost-control item. A 47-51 HRC hardened body, controlled nose geometry and repeatable casting quality let you plan replacement intervals instead of reacting to sudden tooth failures.

Key Features

• Standard pin and retainer fixing without shank modification
• Riser layout optimised to minimise shrinkage porosity at the nose
• Balanced weight distribution reduces side load on the shank
• Uniform 47-51 HRC hardness held from surface to core
• Hardness tested at three points per batch, report supplied with goods

Application

Typical duty: road construction sub-grade ripping, pipeline trench preparation and land clearing, with a good balance between penetration and wear life.

Next Step

Tell us the quantity you consume per season and we will quote a factory price with the packing and labelling you need, including a free sample for fit checking.

Fitting Notes 1U3351

Nose width 76 mm, pin hole 30 mm, unit weight 16.5 kg and overall length 235 mm. Supplied pin retainer plus washer as standard, normalise plus temper treatment, 120 pcs per pallet, reference wear life around 450 hours in medium abrasive rock. Lead time 10-20 working days, MOQ negotiable.

Test and Traceability

Heat numbers are stamped or tagged, hardness results recorded per batch and retained for two years, and any claim can be traced back to the melt and treatment cycle that produced the part.

Technical Specifications

Packing and Delivery

Packing is decided by weight: light tips go in double-wall cartons, heavy tips in woven bags on pallets with a plywood cap. Every carton carries the part number, heat number and quantity so warehouse receiving stays simple.

Buying Advantages

• Factory cost structure because melting, casting and heat treatment are all in house, not outsourced to three subcontractors.
• Custom packing to your warehouse rules: pallet height, carton count, label format and barcode standard.
• 12-month warranty and long-term supply commitment for distributors.
• Container planning help, including weight-balanced loading so you do not pay for air in the box.
• No minimum on trial orders for first-time buyers — test one profile before committing to a season of stock.
• ISO 9001:2015 certified production with dimensional and hardness records retained two years.
