6I6602 Excavator Bucket Teeth Standard Dirt Bucket Tooth for J600 Series

6I6602 Bucket Tooth for J600 Series— Product Description

Where a  ripper works in mixed ground, the 6I6602 Style Tip covers both penetration and wear. The nose is cast slightly proud of the shank line so the tooth, not the shank, absorbs abrasion, and the body is held at 51-56 HRC through section.

Key Features

• Smooth cast surface lowers soil adhesion in wet ground
• Straight shank seat face improves contact and reduces rocking
• Chamfered leading edge shortens break-in time on site
• Through-hardened body instead of a thin case-hardened skin
• Tight bore tolerance on the pin hole for a rattle-free fit

Next Step

Request a quotation with your target port and annual volume; we will reply within one working day with pricing, packing options and a production schedule.

Supply Chain Support

• 12-month warranty plus a documented claim route if a casting fails early.
• Dedicated account engineer for quoting, drawing confirmation and shipping documents.
• Private moulds available when your profile differs from the standard aftermarket shape.
• ISO 9001:2015 records and a hardness report for each heat number, useful for your own quality audits.
• One invoice per container across mixed ground engaging tools, which simplifies customs paperwork for importers.

Application

Typical duty: bulk ripping of hard pan, shale, sandstone and blasted limestone; also used as a wear cap on multi-shank rippers where side wear is the main failure mode.

Fitting Notes 6I6602

Nose width 70 mm, pin hole 35 mm, unit weight 23.1 kg and overall length 410 mm. Supplied pin and retainer as standard, isothermal quench treatment, 120 pcs per pallet, reference wear life around 400 hours in medium abrasive rock. Lead time 7-15 working days, MOQ 50 pieces.

Inspection Before Shipment

Every batch is hardness tested and dimensionally audited against the drawing. Photos of the packed goods, carton marks and the HRC report are sent to you before the container leaves the plant.

Packing and Delivery

Packing is decided by weight: light tips go in double-wall cartons, heavy tips in woven bags on pallets with a plywood cap. Every carton carries the part number, heat number and quantity so warehouse receiving stays simple.
